LILYGO ttgo rgb tft 0.99 inch lcd module

https://www.botshop.co.za/web/image/product.template/1130/image_1920?unique=be3b4d2
(0 review)

119.37 119.37 ZAR 119.37 VAT Included

122.12 VAT Included

Not Available For Sale

This combination does not exist.

Display Displays TFT LILYGO

Internal Reference: LG-008

LILYGO TTGO RGB TFT 0.99 inch LCD Module

If you're a hobbyist looking for an LCD display that's easy to use and packed full of features, look no further than the LILYGO TTGO RGB TFT 0.99-inch LCD Module. This module has advanced driver IC technology with GC9D01, meaning it comes with superior display capabilities such as comprehensive resolution (40(H)RGB X 160(V)).

LILYGO® TTGO T-0.99 Inch LCD display [resolution can reach 40(H)RGB x 160(V)] is a newly developed expansion board with a rectangular design, immersion gold process, sub-black material, and the driver IC of the display is GC9D01.

Two expansion options

  • GH1.25mm 8pin Expansion Interface
  • 2.54mm 10PIN pin Interface

Pin Out

The above image gives you the pinout of the LILYGO TTGO RGB TFT 0.99 inch LCD Module as well as a bit more information on the chipsets and what they are there for.

Size

Technical Specification

Driver IC

GC9D01

LCD Size

0.99 inch

Interface Protocol

SPI 4 LINE

Resolution

40(H)RGB X 160(V)

Temp: Operating

-20°C~70°C; Storage: -30°C~80°C

Color arrangement

RGB Vertical stripe

Active Area

6.096(H) X 24.384(V) mm

Display Size

8.6(H) X 29.8(V)x1.5(D)mm

Documentation

More Information
