UFL-SMA male to pigtail female 150mm

https://www.botshop.co.za/web/image/product.template/1756/image_1920?unique=d42b1b4
(0 review)

40.83 40.83 ZAR 48.04 VAT Included

41.77 VAT Included

Not Available For Sale

This combination does not exist.

Tool

Internal Reference: ACC-195

UFL-SMA male female pigtails

This pigtail has a U.fl Female connector on one end and an SMA Male connector on the other end. U.fl connector is a miniature RF connector for high-frequency signals. The SMA male connector has a center pin surrounded by a barrel with inside threads. SMA connector is coaxial RF connector for coaxial cable with screw connection mechanism.
U.fl connectors are commonly used inside laptops and embedded systems to connect the Wi-Fi antenna to a Mini PCI, Mini PCIe or M.2 Wi-Fi card. Another common use is connecting GPS antennas. SMA connectors are used on LTE equipment - LTE routers and antennas for them. The pigtail uses RG-316 high frequency coaxial cable, which is highly flexible due to the twisted center conductor and is characterized by high electrical stability.
